WG Series Pulse Vacuum Autoclave

This series of pulsation vacuum sterilizers utilizes saturated steam as its sterilization medium which releases a large amount of heat in the stage of condensation and ensures the sterilizing environment at high temperature and at a certain humidity.

Key Features of WG Series Pulse Vacuum Autoclave


  • It is designed and manufactured in accordance with GB150 *the Pressure Vessel. GB8599 the technical requirements of large steam sterilizer-automatic control protocol".

  • The chamber in horizontal rectangular shape with double layers structure is made from S3008

  • Door sealing: Pneumatic scaling: both doors are interlocked and completely conform to the requirements of the specification.

  • With standard GMP authentication interface.

  • Sterilizer piping system: the pipeline is designed with the best configuration. All the spares are from qualified brands at home and abroad.

  • Sterilizer control system: SIEMENS PLC and SIEMENS touch screen, this system is easy to implement the program selection, parameter setting equipment operation, report processing and other functions.

  • It has prefect safety measures The FO value and the temperature time gives double guarantee for sterilization A single parameter control is also available. It has a perfect sterilization record.



Product Parameters of WG Series Pulse Vacuum Autoclave


Design Pressure

0.245Mpa

Working Pressure

0.225Mpa

Design Temperature

139℃

Working Temperature

105-134℃

Vacuum

-0.09Mpa

Temperature Equilibrium

≤±1℃

Water Source Pressure

0.15-0.3Mpa

Compressed Air Pressure

0.3-0.7Mpa

Steam Pressure

0.3-0.7Mpa

Power

AC380V, 50HZ

Model

Chamber Size L×W×H(mm)

Steam Consumption(KG)

Tap Water Consumption(KG)

Power(KW)

Net Weight(KG)

WG-0.25

800×600×600

18KG

35KG

2+24KW

900KG

WG-0.36

1000×600×600

25KG

40KG

2+24KW

1000KG

WG-0.6

1200×610×910

30KG

45KG

3+36KW

1400KG

WG-0.8

1500×610×910

40KG

50KG

3KW

1600KG

WG-1.2

1450×680×1180

48KG

55KG

4KW

1800KG

WG-1.5

1850×680×1180

55KG

60KG

4KW

2000KG

WG-2.0

1600×900×1400

65KG

65KG

4.5KW

2500KG

WG-2.5

1950×900×1400

75KG

75KG

6KW

3000KG

WG-3.0

2400×900×1400

90KG

90KG

8KW

3500KG
