  • HQ-460DY/760DY X-ray Film Printer

HQ-460DY/760DY X-ray Film Printer

  • Dry thermal technology.

  • Daylight load film cartridges.

  • Double tray, supports 4 film sizes.

HQ-460DY/60DY Medical Film Printer Description

The HQ-DY series Dry Imager uses the latest direct dry thermal imaging technology which accommodates a full range of applications, including CT, MR, DSA, and the US, as well as CR/DR applications for GenRad, Orthopaedics, Dental Imaging, and more. The HQ-Series medical film printer dedicates to precision in diagnosis with its outstanding image quality and offers affordable imaging catering to your needs.


HQ-460DY/60DY X-ray Printer Key Features

  • Speed printing, higher efficiency

  • Economical, stable, reliable

  • Compact design, easy installation

  • The straightforward operation, user-friendly


HQ-460DY/60DY X-ray Film Printer Specifications

Model

HQ-430DY

HQ-460DY

HQ-760DY

Print Technology

Direct thermal (dry, daylight-load film)

Spatial Resolution

320dpi (12.6 pixels/mm)

508dpi(20 pixels/mm)

Throughput

14"×17"≥70 sheets/h; 8"×10" ≥90 sheets/h

14" ×17"≥60 sheets/h; 8"×10" ≥80 sheets/h

Grayscale Contrast Resolution

14 bits

Film Transferring Method

Rubbing

Film Tray

One supply tray,

100-sheet capacity total

Two supply trays, 200-sheet capacity total

Film Sizes

8"×10b", 10"×12", 11"×14", 14"×17"

Applicable Film

Medical Dry Thermal Film(blue or clear base)

Interface

10/100/1000 Base-T Ethernet (RJ-45)

Network Protocols

Standard DICOM 3.0 connection

Image Quality

Automatic calibration using a built-in densitometer

Control Panel

Touch Screen, Online Display, Alert, Fault, and Active

Power Supply

100-240VAC, 50/60Hz, 600W

Weight

50Kg

Operating Temperature

5℃-35℃

Operating Humidity

35%-85%

Storage Humidity

30%-95%

Storage Temperature

-22℃-50℃

Base Holding

Optional


HQ-460DY/760DY X-ray Film Printer Images
